AquaSulis UpFlow Plus Coconut Carbon Chlorine Removal Filter System

AquaSulis UpFlow Chlorine Plus Removal made simple

Enhance the purity of your water with the AquaSulis Chlorine Removal UpFlow Filter. Experience whole-house or pre-treatment correction for chlorine removal. This system will reduce and or remove chemicals, protect your health and your chemical sensitive applications. These in/out systems are a second tier filtration solution, the first tier being catridge type filters and the third tier being large tank based systems with automatic control valves that can backwash, rinse and repack the media bed.

Built to last

The AquaSulis Chlorine Removal UpFlow Filter is crafted with carefully chosen components to deliver exceptional performance. Designed for easy installation and long-lasting use, this system ensures your water is consistently chemical free and beneficial for your health and all of your pre-treatment needs.

The filtration in this system is accomplished by a bed of high-quality eco friendly Coconut Carbon media. This medias is specifically produced to remove chemicals, such as chlorine, herbicides and pesticides. These are the most common contaminents found in municipla water supplies.

You can choose from several connection fittings sets to match your plumbing to make for an easy installation. Unlike other systems, this valve head is non-electric and does not require backwashing. Installation only requires an in and out connection, as it comes with a built-in bypass valve. It is recommended to remove sediment before this filter. If you have know sediement issues call or write us to help find the right sediment pre-filter for your application.

Maintenance

The media in this filter will eventually need to be replaced as it can become depleted, worn and inactive. This is dependent on your water conditions, flow rate and amount if water through the system. For most families, you will need to replace the media every 5 to 7 years. This can be done easily by removing the valve head and either shop vacuming it out or washing it out and adding more media. Testing the water with a meter or test strips is the best way to determine if it's time to change out the old media.

Let's Talk Chemicals

Installation Notes

We always recommend removing sediment before the system. Ask us about a suitable pre-filter to match your incoming water conditions.

Resources

• AquaSulis Chlorine Removal UpFlow Filter Manual Here
• This equipment is made in North America by Clack Corp & The Water Guy

Tech Specifications

• High-Quality Coconut Carbon Media
• Gravel Under-Bedding *(on tanks 12" in diameter and larger)
• Clack Media Tank Clack In/Out Filter Valve Head
• Clack Bypass Valve
• Set of Clack Tail Piece Connectors to match your plumbing
• Connection Choices:
• 1" or 3/4" CTS Push Type Fittings
• 1" or 3/4" Brass Sweat/Solder Fittings
• 1" or 3/4" Threaded Fittings.
• Recommended Operating Pressures 40 to 70psi
• Though designed for cold water usage, warm water can be used. Call our technicians to discuss.

What is in the Boxes

• Tank & Riser Rod with Cap.
• Bag(s) of media.
• In/out fill head, By-Pass, Plumbing Connector Set, & Funnel

Chlorine Removal System Specifications

Coconut Chlorine Media
